| New product launch | KBL series new product QVT20 is launched - smaller space and more convenient installation
About Cable entry plate
Cable entry plate, as one of the important industrial accessories in industrial sites, are widely used in various industries. They pass wires, cables, etc. through walls to realize the transmission of power or signals and ensure the stable operation of electrical systems.
With the continuous development of the industrial automation industry, the types of industrial products are constantly increasing. As a result, cabinet design solutions often require cables containing multiple types of prefabricated connectors, which puts great pressure on the design of wiring boards.
Based on changes in market demand, in order to meet the needs of more customer groups, Fuyansheng has launched a new KBL series of threading boards, KBL-QVT20, to help solve such problems for users.
The frame and sealed KT module of the KBL series are openable. KT modules can be added according to needs to meet the use needs of more cables. The KBL series wiring board can very conveniently introduce and fix cables in the cable introduction frame. Quickly route a variety of cables with prefabricated connectors to save manual installation time.
The new KBL-QVT20 can be used to quickly and easily install pre-terminated cables or complete cables,ideal for small machines, equipment and instruments.
Advantages of KBL-QVT20
1️⃣ Easy and quick installation
During the installation process, you only need to pass the assembled KBL-QVT20 through the cabinet, and then tighten the nut along the cable.
2️⃣ Products have a wide range of applications
KBL-QVT20 can be installed in a smaller space and can be used in most usage scenarios.
3️⃣ High sealing degree
4️⃣ Protection level up to IP54
When a sealing gasket is used and the core specifications are correctly selected, the protection level of KBL-QVT20 can reach IP54.
5️⃣ Flexible to use
KBL-QVT20 enables quick routing of various cables with prefabricated connectors, saving manual installation time.
| KBL-QVT20 Technical parameters | |
| Material | polycarbonate |
| Color | gray |
| Flame retardant grade | UL94V-0，spontaneous combustion |
| IP Rating | IP54，Use gaskets and select the correct core specifications |
| Temperature range | -30℃ to +100℃ |
| Characteristic | Halogen-free, silicon-free |
| Thread length | 14mm |
KEL-QVT20 can be quickly installed without screws and can be installed by tightening the frame nuts. Due to the nature of the separable system, modification and repair work can be carried out quickly even when the equipment is in operation. At the same time, the prefabricated plug can remain on the cable without cutting it, making the work easier and the quality of the preassembled cable is guaranteed.
