RJ45 male/RJ45 male、Double ended pre cast PVC non flexible cable、With shielding、Blue sheath、Cat.6a 10Gbps、0C4483-XXX
  • RJ45 male/RJ45 male、Double ended pre cast PVC non flexible cable、With shielding、Blue sheath、Cat.6a 10Gbps、0C4483-XXX
  • RJ45 male/RJ45 male、Double ended pre cast PVC non flexible cable、With shielding、Blue sheath、Cat.6a 10Gbps、0C4483-XXX
  • RJ45 male/RJ45 male、Double ended pre cast PVC non flexible cable、With shielding、Blue sheath、Cat.6a 10Gbps、0C4483-XXX

RJ45 male/RJ45 male、Double ended pre cast PVC non flexible cable、With shielding、Blue sheath、Cat.6a 10Gbps、0C4483-XXX

Ordering code: 0C4483-XXX
Part number : FCC-E838-E838-50-048-VXBC6A-XXX
  • Note: xxx = cable length, can be customized according to needs when ordering, cable length in 0.5m increments,  for example: 005=0.5m, 010=1m, 015=1.5m
Collect Inquiry

Related recommendations

  • Function Parameter
  • Resource Download
  • Related Video
TypeRJ45 straight male conversion to RJ45 straight male
Rated working voltage UB60 V AC/DC
Cable color/materialBlue/PVC（shield）
Number of conductors x conductor cross-section4×2×24 AWG
Degree of protection as per IEC 60529IP20/IP20
Ambient temperature Ta-25...+70 °C
